DE3000-V2 Series

Name: DE3000-V2 Series
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Specification

Item	DE3124-V2	DE3148-V2	DE3160-V2	DE3160-V2@S
Cooperate with	VX3024-V2	VX3048-V2	VX3060-V2	VX3060-V2@S
Management Interface	2Serial port
Back-end Expansion Interface	4-port 412Gbps Mini SAS HD（Primary） 4-port 212Gbps Mini SAS HD（Backup）	4-port 4*12Gbps Mini SAS HD	4-port 4*12Gbps Mini SAS HD	2-port 4*12Gbps Mini SAS HD
HDD	24SATA/SAS/NL SAS Interfaces	48SATA/SAS/NL SAS Interfaces	60SATA/SAS/NL SAS Interfaces	60SATA/SAS/NL SAS Interfaces
Disk Capacity	1 TB, 2 TB, 3 TB, 4 TB , 5 TB, 6 TB,8TB,10TB, 12TB,14TB, 16TB,18TB,20TB
Dimension (W x D x H)	482.0mm × 589.0mm × 175.0 mm	482.0mm × 801.0mm × 178.0 mm Note：for cabinet with 1000mm depth or above	480.6mm× 981.0mm × 178.0 mm Note：for cabinet with 1200mm depth or above
Power Consumption	270W (fully loaded)	450W (fully loaded)	700W (fully loaded)	700W (fully loaded)
Power Supply	100V – 127V/200V – 240V AC；60Hz/50Hz
Weight	Fully loaded：< 40kg	Fully loaded：< 61 kg	Fully loaded：< 92 kg	Fully loaded：<90 kg
Authentication certificate	CE, FCC, RoHS, WEEE
Operating temperature	5°C ~ 40°C / 41°F ~ 104°F
Recommended temperature	10 °C~ 35 °C / 50°F ~ 95°F
Humidity	20%~80% RH (non-condensing)
