OER-SR12, OER-SR22, OER-SR42

Name: OER-SR12, OER-SR22, OER-SR42
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Description

Access Controller

TCP/IP communication, secure and reliable.

Large capacity, max 42,000 cards and 200,000 events.

Different mounting holes for easy installation.

Supports remote upgrade.

Supports real-time monitoring setup.

Supports issuing cardsusing card readers.

Parameter	Description
Model	OER-SR12	OER-SR22	OER-SR42
Name	Single-door access controller	Double-door access controller	Four-door access controller
Card capacity	42,000	42,000	42,000
Event capacity	200,000	200,000	200,000
Communication mode	TCP/IP	TCP/IP	TCP/IP
Door control	1 door	2 doors	4 doors
Card reader	2	4	8
Wiegand input interface (Max DC14V withstand voltage)	2	4	8
Wiegand format	WG18/26/34/66	WG18/26/34/66	WG18/26/34/66
Relay output	1 set (7A)	2 sets (7A)	4 sets (7A)
Door magnetic port	1	2	4
Fire module expansion port	1	1	1
Operating environment	Indoor	Indoor	Indoor
Operating temperature	-10°C to +65°C	-10°C to +65°C	-10°C to +65°C
Rated input voltage	AC 100V to 240V(50Hz or 60Hz)	AC 100V to 240V(50Hz or 60Hz)	AC 100V to 240V(50Hz or 60Hz)
Mount	Wall mount	Wall mount	Wall mount
Dimensions (L x W x H)	235mm x 305mm x 76mm	235mm x 305mm x 76mm	235mm x 305mm x 76mm
