Top 5 Fiber Splicing Machines in Pakistan

Top 5 Fiber Splicing Machines in Pakistan

As Pakistan moves quickly toward digital growth, the need for strong and reliable fiber optic networks is growing fast. A fiber splicing machine is an essential device for establishing the internet in villages, constructing information centers, and working on telecommunications projects. With so many alternatives available, selecting the appropriate splicer may make a significant difference in your choices. For example, how quickly you work, how well the connection works, and how much your project costs. In this blog, we’ve highlighted the top 5 fiber splicing machines available in Pakistan, featuring efficient models like Signal Fire and Shinho that are renowned globally for performance and reliability.

What is a Fiber Splicing Machine?

A fiber splicing machine is a tool used to join two fiber optic cables together. These machines are mainly used in internet setups, telecom systems, and data centers where fiber cables need to be connected to carry data over long distances. Splicing is needed when fiber cables are cut or need to be extended during installation or repair.

How Does a Fiber Splicing Machine Work?

The machine lines up the tiny glass cores of two fiber optic cable and melts them together using heat, usually from an electric arc. This process is called fusion splicing. The goal is to join the fibers with as little signal loss as possible. The machine then checks the quality of the splice and gives a reading, helping technicians know if the connection is strong and reliable.

Why Selecting the Correct Fiber Splicer is Important?

Fiber splicing allows continuous data transmission over considerable distances by joining two fiber ends with little loss and good resilience. A good splicing machine offers:

  • High precision alignment

  • Low splice loss

  • Fast heating and splicing time

  • Reliable performance in the field

As fiber deployment grows in Pakistan (from FTTH to enterprise-level networking), selecting the right fiber splicing machines becomes a smart long-term investment.

Top 5 Fiber Splicing Machines in Pakistan

1)      Signal Fire AI-20

2)      Signal Fire AI-6A

3)      Signal Fire AI-5

4)      Shinho X-97

5)      X500 Active V-groove Fusion Splicer


1. Signal Fire AI-20 Fusion Splicer



Key Features:

  • Core alignment with AI-assisted technology

  • 5-second splicing time, 15-second heating time

  • Equipped with 6 motors for accurate fiber positioning

  • 5-inch high-resolution touch screen display

  • 3-in-1 fiber holder

  • 7800mAh long-life lithium battery (up to 240 splices per charge)

  • Real-time diagnostics and auto-calibration

  • Expandable and closable cooling rack

  • VFL and OPM function to evaluate fiber link transmission quality

  • Protective Case

  • Multilingual settings (approx. 10 languages)

PKR 290,000 – 320,000 is its estimated price in Pakistan

Why is it best?

Signal Fire AI-20 is ideal for professional fiber optic engineers. Even in complex field conditions, its AI-enhanced core alignment guarantees near-perfect splices. This makes it an excellent alternative for Internet Service Providers, telecommunications firms, and FTTH rollouts.


2. Signal Fire AI-6A Fiber Splicing Machines

Key Features:

  • High-precision core alignment

  • Fast splice and heat cycle of 18 seconds

  • 8 seconds high-speed splicing

  • Six motors, core alignment

  • Large capacity lithium battery (5200mAh)

  • Supports multiple fiber types, including SM, MM, DS, and NZDS

  • Wi-Fi connectivity for mobile control

  • Multi-language interface, ruggedized design

PKR 159,000 – 250,000 is the estimated price in Pakistan

Best choice for:

Perfect for medium-to-large-scale fiber installations. With great portability, AI-powered diagnostics, and wireless app control, the Signal Fire AI-6A offers excellent value in its class. Additionally, it is useful for security surveillance, FTTH access, and short-distance external fiber fusion splicing.


3. Signal Fire AI-5 Fusion Splicer



Key Features:

  • Cladding alignment technology

  • 8-second splice time, heater time ~18 seconds

  • Built-in LED for dark environment operation

  • 5200mAh battery (up to 160 splices per cycle)

  • 5-inch color screen

  • 900 and 250μm fibers in tight and loose tubes.

  • Compact body and touchscreen interface

PKR 145,000 – 170,000 is its estimated price in Pakistan

Why Choose It?

The Signal Fire AI-5 is a reliable, entry-level splicer that doesn't cut corners. Designed for field use, it’s a cost-effective solution for fiber technicians, CCTV installers, and telecom repair teams. Also, it is suitable for video surveillance, automation, fiber optic local area networks and security monitoring.


4. Shinho X-97 Fusion Splicer

Key Features:

  • Core alignment system with 6 motors

  • 7-second splice, 26-second heating

  • 5-inch capacitive touch screen

  • Manual and automatic operation modes

  • 5800mah Battery

  • Heating oven and detachable SOC holder.

  • Real-time environmental calibration

  • Up to 200 cycles per battery charge

PKR 270,000 – 300,000 is its estimated price in Pakistan.

Best Use Cases:

Designed for heavy-duty fiber splicing environments. With advanced core alignment and battery life, the Shinho X-97 suits large-scale deployments, including enterprise-level networks and outdoor FTTH, FTTx, security and monitoring projects.


5. X500 Active V-Groove Fusion Splicer

Key Features:

  • Active V-groove alignment for quick and stable splicing

  • User-friendly interface with touch screen

  • Suitable for indoor and outdoor environments

  • Reliable performance

  • 5200mah battery with 250 cycles

  • Cost-effective with high-quality splicing output

PKR 130,000 – 160,000 is its estimated price in Pakistan.

Ideal For:

This model is perfect for fiber installers. X500 Active V-groove Fusion Splicer delivers a simple, fast, portable, and efficient solution. It provides strong performance for smaller projects. This includes CCTV, FTTB, and data cabling setups.



Different Fiber Splicer Models Comparison Table

Model

Alignment Type

Splicing Time

Heating Time

Battery Capacity

Est. Price (PKR)

Best For

Signal Fire AI-20

Core (AI-Assisted)

5 sec

15 sec

7800mAh

290K – 320K

Telecom/FTTH

Signal Fire AI-6A

Core

8 sec

18 sec

5200mAh

210K – 250K

Medium-to-large networks

Signal Fire AI-5

Cladding

8 sec

18 sec

5200mAh

145K – 170K

video surveillance, automation

Shinho X-97

Core

7 sec

26 sec

5800mAh

270K – 300K

Enterprise FTTH, FTTx, security and monitoring

X500 V-Groove

Active V-Groove

~7 sec

~26 sec

5200mAh

130K – 160K

CCTV, FTTB

Where to Buy Fiber Splicing Machines in Pakistan?

Ultra Tech, located in Lahore, is one of the most reliable and authorized distributors in Pakistan for fiber optic tools and telecom equipment. As an authorized dealer for Signal Fire and Shinho, they offer:

  • Genuine products with a warranty

  • Local technical support

  • On-demand stock and nationwide shipping

You can visit them in person at either of their office location # G1, Ground Floor, Odeon Centre, Regal Chowk, Saddar, Karachi, Pakistan or office # 21, 1st floor, Hafeez Center, Gulberg 3, Lahore, Pakistan. Furthermore, you can also contact them via 042-35712273-74-75 and explore their products by visiting their website or emailing at info@ultratech.pk

Closing Words

Selecting the right Fiber Splicing Machines is very important. It ensures strong, low-loss fiber connections. Pakistan is experiencing an increase in demand for quick and consistent connectivity.  Every model listed in this blog, from the smart AI-20 to the affordably priced X500, meets various project sizes and technological requirements.

Regardless of your role as a telecom contractor or professional installer, selecting the appropriate splicer increases efficiency, lowers mistakes, and secures your network for the future.
