PWR-DC5611-P@NB

Name: PWR-DC5611-P@NB
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Specification

PSE	PWR-DC5611-P@NB
INPUT	AC 100-240V~ 50/60Hz 2AMax
OUTPUT	DC 56V/1.1A (+2%,-4%)
Protection/Environmental
Protection	Output over current protection: 1.2A Short circuit protection (Yes)
Protection	Surge protection power input port meets EN 61000-4-5 criterion B: L-N 2KV L,N-PE 4KV Output communication port :1kV differential mode (criterion B)
Enviromental
Storage Temperature	-40℃~70℃(-40℉~158℉)
Operating Temperature	-20℃~60℃(-4℉~140℉)
Working humidity	<95% RH
Physical Properties
Weight	473g(1.04lb)
Dimension(LxWxH)	183mmx70.8mmx37mm(7.20”x2.79”x1.46”)
Installation mode	Plane installation
Color	Black
Input plug	3-pin plug
Power Out Pin	Endspan 1.2(+),3.6(-)Midspan 4.5(+),7.8(-)
Output plug	18.5±0.5mm (Network Cable Connector)
Safety Standards
Certification	CCC,CB,CE,FCC,UL
