Ultratech

NSW1010 Series

Name: NSW1010 Series
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Description
Reviews

Specification

Item	NSW1010-5T-IN		NSW1010-8T-IN	NSW1010-5GT-IN	NSW1010-8GT-IN
Service port	5 x 10/100Mbps port (RJ45)		8 x10/100Mbps port (RJ45)	5 x 10/100/1000Mbps port (RJ45)	8 x 10/100/1000Mbps port (RJ45)
Network media	10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m)			10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) 1000Base-TX: Cat5e or higher UTP/STP (≤100m)
Standards	IEEE802.3 (Ethernet) IEEE802.3u (fast Ethernet) IEEE802.3x (flow control)			IEEE802.3 (Ethernet) IEEE802.3u (fast Ethernet) IEEE802.3ab (Gigabit Ethernet) IEEE802.3x (flow control)
Switching capacity	1Gbps		1.6Gbps	10Gbps	16Gbps
Packet forwarding rate	0.744Mpps		1.19Mpps	7.44Mpps	11.9Mpps
MAC	2K
Jumbo frame	15K
Transfer mode	Store-and-forward
Dimensions	Product: 925121.5mm Packaging: 938251mm		Product: 1456021.5mm Packaging: 1468850mm	Product: 925121.5mm Packaging: 938251mm	Product: 1456021.5mm Packaging: 1468850mm
Carton information	Carton dimensions: 435280395mm Carton quantity: 100PCS Carton weight: 14.2kg		Carton dimensions: 530475315mm Carton quantity: 100PCS Carton weight: 17.6kg	Carton dimensions: 435280395mm Carton quantity: 100PCS Carton weight: 14.2kg	Carton dimensions: 530475315mm Carton quantity: 100PCS Carton weight: 17.6kg
Weight	Product: 0.062kg Packaging: 0.132kg		Product: 0.111kg Packaging: 0.166kg	Product: 0.062kg Packaging: 0.132kg	Product: 0.111kg Packaging: 0.166kg
Operating voltage	Adapter input voltage: AC 100V to 240V Switch input voltage: 5V, 1A
Mount method	Desktop mount, wall mount
Fan	Fanless	Fanless		Fanless	Fanless
Operating temperature	0°C to 40°C
Operating humidity	10% to 90% RH, noncondensing
Storage temperature	-20°C to 70°C
Storage humidity	5% to 90% RH, noncondensing
Indicator	Power: Steady on: Connected to the power Off: Disconnected to the power
	Port: Steady on: Connected to the port Blinking: Transmitting data Off: Disconnected to the port
