Ultratech

VX1800-V2 Series

Name: VX1800-V2 Series
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Description
Reviews

Specification

Item		VX1824-V2	VX1848-V2
Controller		1
performance	Video Mode	512-channel(1024Mbps) recording, 512-channel(1024Mbps) forwording, 51-channel(102Mbps)playback
	IPSAN Mode	512-channel(1024Mbps) recording, 51-channel(102Mbps)playback
Storage controller		Intel 64-bit multi-core processor
Memory		8 GB, up to 64 GB
Front-end Service Interface		5-port 10/100/1000 Mbps Ethernet interface 4-port 10/100/1000 Mbps Ethernet interface module（optional） 2-port 10 GE SFP＋ interface module（optional） 4-port 10 GE SFP＋ interface module（optional）
Back-end Expansion Interface		2-port 4*12 Gbps Mini SAS HD
Host Connection		Up to 1024
HDD		24 SATA interfaces	48 SATA interfaces
Disk Capacity		1 TB, 2 TB, 3 TB, 4 TB , 5 TB, 6 TB, 8 TB , 10 TB, 12 TB, 14 TB , 16 TB, 18 TB, 20TB
RAID		JBOD and RAID 0,1,10, 5, 50,6 Dedicated hot-spare disk and global hot-spare disk
Maximum Number of Logic Resources		1024
Protocol Supported		iSCSI、NFS、SMB、FTP
Alarm Feature		Indicator alarm, mail alarm, SNMP Trap alarm, and short message alarm
Operating System		Windows and Linux
Power Supply		1 default, 1 optional
Battery		1default，1 optional
Dimension (H ×W×D)		Controller enclosure: 175.0mm×481.6mm×589.0mm	Controller enclosure: 178mm X 481.6mm X801mm Note：for standard cabinet with 1000mm depth or above
Power Consumption		Controller enclosure :< 350 W (fully configured)	Controller enclosure: < 600 W (fully configured)
Power Supply		100 V – 127 V/ 200 V – 240 V AC, 60 Hz/50 Hz
Weight		Controller enclosure :Fully configured：< 43 kg	Controller enclosure : Fully configured：< 60 kg
Authentication certificate		CE, FCC, RoHS, WEEE
Operating temperature		5 °C~40°C / 41 °F ~ 104 °F,(10°C~ 35°C / 50 °F ~ 95°F Recommended)
