CSS326-24G-2S+RM SwOS powered 24 port Gigabit Ethernet switch with two SFP+ ports in 1U rackmount case

MikroTik

CSS326-24G-2S+RM

Name: CSS326-24G-2S+RM
Brand: MikroTik
Availability: InStock
Rating: 5.0 (10 reviews)

SwOS powered 24 port Gigabit Ethernet switch with two SFP+ ports in 1U rackmount case

Contact Now

DataSheet PDF

Description
Reviews

Description

Cloud Smart Switch 326-24G-2S+RM: Elevate Your Network with Advanced Switching Capabilities

Take your network to the next level with the Cloud Smart Switch 326-24G-2S+RM, a powerful and feature-rich 24-port Gigabit Ethernet switch with two SFP+ ports in a compact 1U rackmount case. Powered by SwOS, this switch provides wire-speed connectivity and a range of advanced switching features to meet the demands of your growing network.

Key Features:

24 Gigabit Ethernet ports for high-speed connectivity
2 SFP+ ports for flexible fiber connections
Manage port-to-port forwarding for efficient traffic management
Apply MAC filters for enhanced security
Configure VLANs for network segmentation and organization
Mirror traffic for monitoring and troubleshooting
Apply bandwidth limitation for optimized network performance
Adjust MAC and IP header fields for customized networking

SFP Cage Support:

1.25 Gb SFP modules
10 Gb SFP+ modules

Upgrade your network with the Cloud Smart Switch 326-24G-2S+RM, offering advanced switching features, flexibility, and reliability.

Specifications

Details
Product code	CSS326-24G-2S+RM
Switch chip model	98DX3216
Dimensions	443 x 144 x 44 mm
Operating System	SwOS
Storage size	2 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-20°C to 70°C
Suggested price	$159.00

Powering

Details
Number of DC inputs	2 (PoE-IN, DC jack)
DC jack input Voltage	10-30 V
Max power consumption	19 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	10-30 V
