GS-POE15W-MG/GS-POE30W-MG/GS-POE60W-MG

Product Description

Reliable and Efficient Power Over Ethernet Solutions

The Grandstream GS-POE15W-MG, GS-POE30W-MG, and GS-POE60W-MG are high-performance Power over Ethernet Injectors designed to deliver reliable power and data connectivity to a wide range of PoE-enabled devices. These plug-and-play injectors provide a simple and cost-effective solution for powering Grandstream's GWN series Wi-Fi Access Points, IP phones, IP cameras, and other PoE-powered devices without the need for additional power outlets or complex wiring.

Whether you need to power a single access point, a VoIP phone, or a high-power device requiring PoE++ support, the GS-POE series offers a solution tailored to your specific requirements. With compliance to the latest IEEE 802.3af/at/bt standards and support for high-speed network ports, these PoE injectors ensure seamless power delivery and data transmission for your business network.

Three Models for Every Power Requirement

GS-POE15W-MG – Standard PoE Power

• Compliance: IEEE 802.3af

• Output Power: 20W

• Network Ports: 2x 2.5Gbps RJ45 (LAN IN & LAN OUT with PoE)

• Ideal For: Powering standard PoE devices such as basic IP phones, low-power Wi-Fi access points, and small IP cameras.

• Output Voltage: 54VDC (1,2+; 3,6-)

GS-POE30W-MG – PoE+ for Higher-Power Devices

• Compliance: IEEE 802.3af/at

• Output Power: 30.2W

• Network Ports: 2x 2.5Gbps RJ45 (LAN IN & LAN OUT with PoE)

• Ideal For: Powering PoE+ devices such as advanced IP phones, PTZ cameras, and Wi-Fi 6 access points.

• Output Voltage: 54VDC (1,2/4,5+; 3,6/7,8-)

GS-POE60W-MG – PoE++ for High-Power Applications

• Compliance: IEEE 802.3af/at/bt

• Output Power: 60W

• Network Ports: 2x 10Gbps RJ45 (LAN IN & LAN OUT with PoE)

• Ideal For: Powering high-power PoE++ devices such as outdoor access points, high-end PTZ cameras, and network switches.

• Output Voltage: 54VDC (1,2/4,5+; 3,6/7,8-)

Key Features and Benefits

• Plug-and-Play Simplicity: No configuration required. Simply connect the power adapter, plug in your Ethernet cables, and power your PoE devices instantly.

• IEEE 802.3 Compliance: Full compliance with IEEE 802.3af (PoE), 802.3at (PoE+), and 802.3bt (PoE++) standards, ensuring compatibility with a wide range of devices.

• High-Speed Network Ports: The GS-POE15W-MG and GS-POE30W-MG feature 2.5Gbps network ports, while the GS-POE60W-MG offers 10Gbps ports, ensuring that network speeds are never bottlenecked.

• Built-In Power Adapter: Each injector includes a built-in power adapter with a 1.2m AC cable, simplifying installation and reducing cable clutter.

• 54VDC Output Voltage: Provides stable and consistent power delivery to connected devices.

• LED Status Indicators: Blue LED indicates power on, while Purple LED indicates PoE load, providing clear visual status at a glance.

Technical Specifications

Easy Installation and Versatile Deployment

The Grandstream GS-POE series injectors are designed for effortless deployment in any environment:

• Compact Form Factor: The sleek and compact design allows for easy placement on desks, shelves, or mounted in equipment racks.

• No Configuration Required: Simply plug in the power adapter, connect your network switch to the LAN IN port, and connect your PoE device to the LAN OUT with PoE port.

• Built-In Power Adapter: The integrated 1.2m AC cable eliminates the need for a separate power brick, simplifying installation and reducing cable clutter.

• LED Status Monitoring: Clearly visible LEDs provide instant confirmation of power status and PoE load.

Ideal Applications

The Grandstream GS-POE series injectors are perfect for a wide range of applications:

• Powering Wi-Fi Access Points: Deploy GWN series access points in locations where PoE switches are not available.

• IP Phone Installations: Power Grandstream IP phones for VoIP deployments in offices, hotels, and call centers.

• IP Camera Connectivity: Power and connect IP cameras for surveillance systems in retail, hospitality, and industrial environments.

• Remote Device Deployment: Deploy PoE devices in locations without nearby power outlets, such as ceilings, outdoor enclosures, and remote offices.

• Network Expansion: Easily add PoE capabilities to existing network infrastructure without upgrading switches.

Why Choose Grandstream PoE Injectors?

• Reliable Performance: Designed and tested for compatibility with Grandstream's full range of PoE-powered devices.

• Industry-Standard Compliance: Full compliance with IEEE 802.3af/at/bt ensures compatibility with virtually any PoE device.

• High-Speed Connectivity: 2.5G and 10G network ports ensure no bottleneck for high-bandwidth applications.

• Simple and Cost-Effective: Eliminates the need for expensive PoE switches or additional power outlets.

• Built to Last: Robust construction and high-quality components ensure long-term reliability.

• Easy Troubleshooting: LED indicators provide clear visual status for quick diagnostics.

Package Contents

Each Grandstream GS-POE injector includes:

• GS-POE15W-MG, GS-POE30W-MG, or GS-POE60W-MG PoE Injector

• 1.2m AC Power Cable

• Quick Installation Guide

• Certification Regulatory Paper

Available at Ultratech

The Grandstream GS-POE15W-MG, GS-POE30W-MG, and GS-POE60W-MG Power over Ethernet Injectors are available now at Ultratech. Our team of networking experts can help you select the right injector for your specific power requirements, provide deployment guidance, and offer competitive pricing for volume orders.

Contact Ultratech today to learn more about the GS-POE series, request a quote, or place your order. Power your PoE devices with Grandstream's reliable and efficient PoE injector solutions.
