netPower 15FR An outdoor 18 port switch with 15 reverse PoE ports and SFP. Cut costs, not speed – choose GPEN over GPON!

MikroTik

netPower 15FR

Name: netPower 15FR
Brand: MikroTik
Availability: InStock
Rating: 5.0 (10 reviews)

An outdoor 18 port switch with 15 reverse PoE ports and SFP. Cut costs, not speed – choose GPEN over GPON

Contact Now

DataSheet PDF

Description
Reviews

Description

netPower 15FR: Revolutionize Fiber Networking with Cost-Effective and Versatile Switching

Say goodbye to expensive GPON base stations and optical splitters with the netPower 15FR switch, part of our innovative GPEN concept. This game-changing solution brings the speed and versatility of fiber networking to your doorstep, while leveraging the advantages of Ethernet.

Easy Deployment and Low-Cost Solution

Designed for ISPs, netPower 15FR offers an easy-to-deploy and cost-effective way to deliver high-speed internet to individual apartments. With 15 reverse PoE ports, you can forget about power options in the attic or utility room. This switch can draw power from a single client, depending on your setup. Additionally, Ethernet port 15 can power other PoE-capable devices with the same voltage.

Fiber Connectivity and Outdoor Durability

Two SFP ports provide fiber connectivity, while the outdoor enclosure ensures the switch can withstand various environments, including damp attics, elevator shafts, and poles with hose clamps.

High-Performance Switching

netPower 15FR boasts a non-blocking throughput of 3.6 Gbps, switching capacity of 7.2 Gbps, and forwarding rate of 5.4 Mpps, making it an ideal solution for high-speed networking needs.

Key Benefits:

Cost-effective alternative to GPON base stations and optical splitters
Easy deployment and low maintenance
15 reverse PoE ports for flexible power options
Fiber connectivity with two SFP ports
Outdoor enclosure for durability in various environments
High-performance switching capabilities

Upgrade your fiber networking with netPower 15FR - bringing cost down and speed up!

Specifications

Details
Product code	CRS318-1Fi-15Fr-2S-OUT
Architecture	ARM 32bit
CPU	98DX224S
CPU core count	1
CPU nominal frequency	800 MHz
Switch chip model	98DX224S
Dimensions	304 x 212 x 71 mm
RouterOS license	5
Operating System	RouterOS / SwitchOS
Size of RAM	256 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-40°C to 70°C
Suggested price	$169.00

Powering

Details
Number of DC inputs	16 (PoE-IN, DC jack)
DC jack input Voltage	18-57 V
Max power consumption	29 W
Max power consumption without attachments	10 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	18-57 V (recommended 36-57V)

PoE-out

Details
PoE-out ports	Ether15
PoE out	Passive PoE
Max out per port output (input 18-30 V)	0.75 A
Max out per port output (input 30-57 V)	0.5 A
Max total out (A)	0.75 A
