Grandstream GWN7670E: Enterprise Dual-Band Wi-Fi 7 Access Point

Next-Generation Wireless Performance for High-Density Environments

The Grandstream GWN7670E represents a significant leap forward in enterprise wireless networking, combining the power of Wi-Fi 7 technology with innovative Xtra Range 2.0 capabilities to deliver exceptional performance, expansive coverage, and enterprise-grade security. This dual-band access point is purpose-built for medium-scale, high-density wireless environments, making it the ideal solution for modern offices, retail spaces, educational institutions, and other demanding indoor settings.

Key Feature Highlights

• 3.6 Gbps Aggregate Wireless Throughput – Experience exceptional wireless performance that seamlessly handles bandwidth-intensive applications, including 4K video streaming, large file transfers, and real-time collaboration tools without latency or buffering.

• 2.5 Gbps Wired Throughput – The high-speed 2.5 GbE uplink ensures your wireless network maintains a robust, congestion-free connection to your core infrastructure, eliminating bottlenecks and maximizing overall network efficiency.

• Wi-Fi 7 Certified Connectivity – Leverages the latest IEEE 802.11be standard with dual-band 2.4 GHz 2×2:2 and 5 GHz 3×3:2 MU-MIMO technology, featuring Multi-Link Operation (MLO), 4K QAM, Multi-RU, and preamble puncturing for unparalleled spectral efficiency and performance.

• Xtra Range 2.0 Technology – Revolutionary signal enhancement technology on the 5 GHz band dramatically boosts signal penetration, shattering traditional coverage barriers and delivering seamless 360-degree connectivity throughout your facility.

• 175-Meter Coverage Range – Delivers reliable, enterprise-grade connectivity across vast indoor spaces, reducing the number of access points needed and simplifying deployment in large facilities.

• 512 Concurrent Client Devices – Supports up to 512 simultaneous connections without compromising speed or performance, making it ideal for high-density environments where numerous devices compete for bandwidth.

• Advanced QoS – Guarantees flawless performance for real-time and low-latency applications, ensuring critical business communications, video conferencing, and streaming services receive priority bandwidth.

• 1,000 PPSK Accounts – Provides secure, individualized user access through Private Pre-Shared Key technology, eliminating the complexity of RADIUS servers while maintaining granular access control for every user.

• Enterprise-Grade Security – Features anti-hacking secure boot, critical data and control lockdown via digital signatures, and unique security certificates with random default passwords for every device, ensuring comprehensive protection against evolving cyber threats.

• Flexible Management Options – Beyond the intuitive local Web UI, manage your access points through GDMS Networking (Grandstream's premier cloud management platform) or GWN Manager for comprehensive on-premises control, offering complete visibility and control from anywhere.

Revolutionary Xtra Range 2.0 Technology

The GWN7670E sets itself apart with groundbreaking Xtra Range 2.0 technology on the 5 GHz band. This innovative feature dramatically enhances signal penetration through walls, floors, and other obstacles, effectively shattering traditional coverage limitations. The result is seamless 360-degree connectivity that ensures every corner of your facility receives robust, reliable Wi-Fi coverage, eliminating dead zones and improving user experience across the entire environment.

Enterprise-Grade Technology

Wi-Fi 7 Performance

The GWN7670E harnesses the full power of the Wi-Fi 7 standard, delivering exceptional throughput and expansive coverage through its advanced 2.4 GHz 2×2:2 and 5 GHz 3×3:2 MU-MIMO configuration. Combined with DL/UL OFDMA technology, Multi-Link Operation (MLO), 4K QAM, Multi-RU, and preamble puncturing, this access point provides the spectral efficiency and performance required for today's most demanding applications.

Advanced Quality of Service

Sophisticated QoS capabilities guarantee flawless performance for real-time and low-latency applications. Whether supporting voice over IP, video conferencing, online gaming, or other latency-sensitive applications, the GWN7670E ensures that critical traffic receives the bandwidth and priority it needs for optimal performance.

Intelligent Network Management

Beyond local Web UI control, the GWN7670E supports GDMS Networking, a premier cloud-based management platform delivering real-time monitoring, instant alerts, and in-depth statistics. Accessible from anywhere via web browser or mobile app, GDMS Networking makes AP management across multiple locations simpler and more intuitive than ever. For organizations preferring on-premises control, GWN Manager provides comprehensive management capabilities for up to 3,000 GWN APs.

Robust Security Framework

Enterprise-grade security is built into every aspect of the GWN7670E. Features include:

• Anti-Hacking Secure Boot – Protects against unauthorized firmware modifications

• Digital Signature Lockdown – Ensures critical data and control remain secure

• WPA3 Encryption (Personal & Enterprise)

• Enhanced Open (OWE) for secure open networks

• RADIUS-based 802.1X authentication

• Rogue AP detection and containment

• ARP and ND attack defense

• MAC filtering and client isolation

• Unique security certificate and random default password per device

Application Scenarios

Corporate Offices

Creates a high-performance mobile working environment for employees in medium and large offices without sacrificing speed. Supports seamless roaming, video conferencing, and heavy collaboration tools, ensuring productivity remains high even during peak usage periods.

Retail Environments

Enhances the customer experience and streamlines operations by providing robust, dedicated Wi-Fi for both guests and staff. Supports point-of-sale systems, inventory management, customer engagement applications, and digital signage with reliable, high-speed connectivity.

Educational Institutions

Helps staff and students excel with rapid, reliable wireless connections for research, digital learning, online assessments, and collaborative projects, even in the most demanding academic environments with hundreds of simultaneous users.

Technical Specifications

Hardware

• Interface: 1 × 2.5 GbE (RJ45) with PoE+

• Reset: 1 × Reset Pinhole

• LED: System LED (tri-color for device tracking and status)

Power and Energy

• PoE Standard: 802.3at (PoE+)

• Max Power Consumption: 22 W

Environmental

• Operating Temperature: 0°C to 45°C (32°F to 113°F)

• Storage Temperature: -30°C to 60°C (-22°F to 140°F)

• Humidity: 10%–90% (non-condensing)

Wireless Specifications

• Wi-Fi Standards: Wi-Fi 7 (IEEE 802.11a/b/g/n/ac/ax/be)

• Bands: Dual-band (2.4 GHz & 5 GHz)

• MU-MIMO: 2.4 GHz 2×2:2, 5 GHz 3×3:2

• SSIDs: 48 SSIDs total, 16 per radio

• Client Capacity: Up to 512 concurrent clients

Flexible Deployment Options

The GWN7670E is engineered for total deployment flexibility with its versatile multi-pattern bracket system. The included mounting accessories ensure a seamless installation experience—whether you're mounting on walls, ceilings, or various standard junction boxes. The access point establishes a high-speed wired uplink to your routers and switches, serving as a powerful wireless hub that broadcasts a robust signal to provide high-performance Wi-Fi for all your critical client devices.

Package Contents

• 1 × GWN7670E Wi-Fi 7 Wireless AP

• 1 × Quick Installation Guide

• 1 × Regulatory Paper

• 1 × Mounting Bracket

• 1 × Ceiling Mounting Bracket

• 3 × Plastic Expansion Bolts

• 3 × Pan Head Tapping Screws (ST3.5 × 20 mm)

• 3 × Pan Head Machine Screws (M3 × 50 mm)

• 3 × M3 Nuts

Ordering Information

GWN7670E: Dual-Band Wi-Fi 7 Access Point, 1 × 2.5 GbE, BE3600, 2.4G 2×2:2 and 5G 3×3:2 MU-MIMO

The Grandstream GWN7670E is the ultimate solution for organizations seeking to deploy next-generation Wi-Fi 7 connectivity with exceptional coverage and security. With its revolutionary Xtra Range 2.0 technology, advanced QoS capabilities, and flexible management options, this access point delivers the performance, reliability, and security required for today's most demanding enterprise environments. Whether upgrading an existing network or building a new one, the GWN7670E ensures your organization is ready for the wireless demands of tomorrow.
