MW77XX-RO

Name: MW77XX-RO
Brand: Ultratech
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Contact Now

Specification

Model	MW7739-RO	MW7748-RO
Module
Pixel pitch	P3.9	P4.8
Resolution (W*H)	64*64	52*52
Dimensions (mm)	250*250
Cabinet
Dimensions (mm)	50050082
Resolution (W*H)	128*128	104*104
Weight (kg/pcs)	6.5
Pixel density (pitch/m²)	65536	43264
Material	Die-cast aluminum
Optical
Brightness (nits)	4500-5000 adjustable
Contrast ratio	5000:1
Color temperature (K)	2000 to 9300
Viewing angle (H/V)	160°/120°
Processing performance
Grayscale (bit)	14
Scan (S)	8	7
Refresh rate (Hz)	3840
Single pixel brightness correction	Support
Single pixel color correction	Support
Center distance deviation of LED	<3%
Brightness uniformity	≥95%
Color uniformity (Cx,Cy)	±0.003
Electrical
Average power consumption (W/m²)	280
Max. power consumption (W/m²)	830
Power supply (V)	AC 100 to 240
Drive mode	Constant current driving
General
Maintenance mode	Front/rear maintenance
Ingress protection	IP65
Operating temperature	-20°C to 50°C
Operating humidity	10% to 90% RH non-condensing
Storage temperature	-40°C to 60°C
Storage humidity	10% to 95% RH non-condensing
LED lifetime (h)	100000
Certifications	RoHS
