4GE+1POTS+WiFi 5+2USB ONU Model: HG325DAC Spec: 4*GE+1POTS(2POTS option)+WiFi 5+USB 3.0 Weight: 420g

V.SOL

4GE+1POTS+WiFi 5+2USB ONU

Name: 4GE+1POTS+WiFi 5+2USB ONU
Brand: V.SOL
Availability: InStock
Rating: 5.0 (10 reviews)

Model: HG325DAC , Spec: 4*GE+1POTS(2POTS option)+WiFi 5+USB 3.0

Contact Now

DataSheet PDF

Description
Reviews

Description

HG325DAC: All-in-One ONU for High-Speed Connectivity

The HG325DAC ONU is a compact and versatile device that combines high-speed internet, voice, and data services in one. With 4 Gigabit Ethernet ports, 1 POTS (optional 2 POTS) port, WiFi 5 capabilities, and 2 USB 3.0 ports, it's perfect for small to medium-sized networks. Weighing just 420g, it's ideal for FTTH and FTTB applications.

Key Features:

4 x Gigabit Ethernet ports
1 x POTS (optional 2 x POTS) port
WiFi 5 capabilities
2 x USB 3.0 ports
Compact design (420g)

Specifications

○ Hardware Parameter
Dimension	178mm×120mm×30m(L×W×H)
Net weight	0.42Kg
Operating condition	Operating temp: 0°C~+50°C Operating humidity:10%~90%（non-condensing）
Storing condition	Storing temp: -30℃~+70°C Storing humidity: 10%~90% (non-condensed)
Power adapter	DC 12V/1.5A
Power supply	12W
Interface	4GE+1POTS+2USB+WiFi 5
LED Indicators	PWR, LOS, PON, LAN1 ~ LAM4, 2.4G, 5.0G, USB0, USB1, PHONE
USB	1USB 2.0+1USB 3.0

○ Interface Parameter
PON interface	1XPON port(EPON PX20+ & GPON Class B+) SC single mode, SC/UPC connector TX optical power: 0～+4dBm RX sensitivity: -27dBm Overload optical power: -3dBm(EPON) or -8dBm(GPON) Transmission distance: 20KM Wavelength: TX 1310nm, RX1490nm
WIFI interface	Compliant with IEEE802.11b/g/n/ac WiFi:2.4GHz 2×2, 5.8GHz 2×2, 5dBi antenna, rate up to 1.167Gbps,Multiple SSID TX power: 11n–22dBm/11ac–24dBm
USB interface	2*USB For Shared Storage/Printer or Console
LAN interface	2*GE, Auto-negotiation RJ45 connectors
Pots interface	1*FXS, RJ11 connector

○ Function Data
O&M	OAM/OMCI,Telnet,WEB,TR069 Support full management of HGU functions by VSOL OLT
Connect Mode	Support bridge, router & bridge/router mixed mode
Data Service Functions	Full speed non-blocking switching 2K MAC address table 64 full range VLAN ID Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc Support auto polarity detection of Ethernet ports (AUTO MDIX) Integrated IEEE802.1p QoS with four level priority queues Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy
Wireless	Integrated 802.11b/g/n/ac Authentication:WEP/WAP-PSK(TKIP)/ WAP2-PSK(AES) Modulation type:DSSS,CCK and OFDM Encoding scheme:BPSK,QPSK,16QAM and 64QAM
VoIP	SIP and IMS SIP G.711a/G.711u/G.722/G.729 Codec Echo cancellation,VAD/CNG,DTMF Relay T.30/T.38 FAX Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Conference Line testing according to GR-909
L3	Support NAT, Firewall Support IPv4/IPv6 dual stack
Other function	Integrated OAM/OMCI remote configuration and maintenance function Support rich QinQ VLAN functions and IGMP snooping multicast features
