1GE+1FE+1POTS+CATV+WiFi ONU

Name: 1GE+1FE+1POTS+CATV+WiFi ONU
Brand: V.SOL
Availability: InStock
Rating: 5.0 (10 reviews)

Model: HG323RGWT , Spec: 1*GE+1FE+1POTS+WiFi 4+CATV

Contact Now

DataSheet PDF

Description
Reviews

Description

HG323RGWT ONU

The HG323RGWT is a cutting-edge Optical Network Unit (ONU) that offers a comprehensive range of features and interfaces for fiber-based networks. With a compact and lightweight design (315g), this ONU is ideal for various applications, including home networking, small business networking, and enterprise networking.

Key Features:

1 Gigabit Ethernet (GE) port for high-speed internet access
1 Fast Ethernet (FE) port for additional device connectivity
1 POTS (Plain Old Telephone Service) port for voice connectivity
WiFi 4 (802.11n) support for wireless connectivity
CATV (Community Antenna Television) support for cable television services

Technical Specifications:

Model: HG323RGWT
Interface: 1 GE + 1 FE + 1 POTS + WiFi 4 + CATV
Weight: 315g

The HG323RGWT ONU is a versatile and reliable solution for service providers and end-users seeking a high-performance ONU for their fiber-based networks.

Specifications

○ Hardware Parameter
Dimension	185mm×120mm×34m(L×W×H)
Net weight	0.29Kg
Operating condition	Operating temp: 0 ~ +50°C Operating humidity: 10 ~ 90% (non-condensed)
Storing condition	Storing temp: -30 ~ +60°C Storing humidity: 10 ~ 90% (non-condensed)
Power adapter	DC 12V/1A, external AC-DC power adaptor
Power supply	≤8W
Interfaces	1GE+1FE+1POTS+WiFi 4+CATV
Indicators	PWR, LOS、GE、FE、FXS、CATV、WiFi

○ Interface parameter
PON interface	l 1 XPON port(EPON PX20+ and GPON Class B+) l SC/APC connector l TX optical power: 0 to +4 dBm(↑) l RX optical power: -8 to -28 dBm(↓) l Transmission distance: 20KM l Maximum transfer rate: 2.488Gbps(↓), 1.2488Gbps(↑) l RX wavelength: 1490nm(↓),1550nm(↓) l TX wavelength: 1310nm(↑)
WIFI interface	l Compliant with IEEE802.11b/g/n l Operating frequency: 2.400-2.4835GHz l support MIMO, rate up to 300Mbps l 2T2R,2 external antenna 5dBi l Support: multiple SSID l Channel:13 l Modulation type: DSSS、CCK and OFDM l Encoding scheme: BPSK、QPSK、16QAM and 64QAM
LAN interface	1 x 10/100/1000Mbps and 1 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
POTS interface	l 1 FXS, RJ11 connectors l Support: G.711/G.723/G.726/G.729 codec l Support: T.30/T.38/G.711 Fax mode, DTMF Relay l Line testing according to GR-909
CATV interface	l Optical receiving wavelength: 1550±10nm l Optical input range: +2～-18dBm l Optical reflection loss: ≥40dB l RF frequency range: 47～1000MHz l RF output impedance: 75Ω l RF output level and AGC range: ≥81±2dBuv@+1～-10dBm ≥79±2dBuv@ 0～-11dBm ≥77±2dBuv@-1～-12dBm ≥75±2dBuv@-2～-13dBm ≥73±2dBuv@-3～-14dBm ≥71±2dBuv@-4～-15dBm l MER: ≥32dB(-14dBm optical input)
