V.SOL

1GE + 1FE WiFi ONU

Name: 1GE + 1FE WiFi ONU
Brand: V.SOL
Availability: InStock
Rating: 5.0 (10 reviews)

Model: V2802RGW , Spec: 1*GE+1FE+WiFi 4

Contact Now

DataSheet PDF

Description
Reviews

Description

Product Description: V2802RGW ONU

The V2802RGW ONU (Optical Network Unit) is a compact and powerful device that offers a range of connectivity options for your home or small business. With its sleek design and robust features, this ONU is perfect for those seeking reliable and high-speed internet connectivity.

Key Features:

1 Gigabit Ethernet Port: High-speed internet connectivity for devices
1 Fast Ethernet Port: Additional connectivity option for devices
WiFi: Wireless connectivity for devices, enabling flexible networking
4 WiFi Antennas: Enhanced wireless coverage and stability

Product Specifications:

Model: V2802RGW
Type: 1GE + 1FE WiFi ONU
Specification: 1*GE+1FE+WiFi 4

This ONU is designed to provide reliable, high-speed internet connectivity and wireless coverage, making it an ideal choice for those seeking a robust and versatile networking solution.

Specifications

○ Hardware Parameter
Dimension	185mm×120mm×34mm（L×W×H）
Net weight	0.24Kg
Operating condition	l Operating temp: 0 ~ +50°C l Operating humidity: 10 ~ 90% (non-condensed)
Storing condition	l Storing temp: -30 ~ +60°C l Storing humidity: 10 ~ 90% (non-condensed)
Power adapter	DC 12V, 1A , external AC-DC power adaptor
Power supply	≤ 7W
Interfaces	1GE+1FE+WiFi 4
Indicators	POWER、LOS、PON、GE、FE、WiFi

○ Interface parameter
PON interface	l 1 XPON port(EPON PX20+ & GPON Class B+) l SC single mode, SC/UPC connector l TX optical power: 0～+4dBm l RX sensitivity: -27dBm l Overload optical power: -3dBm(EPON) or -8dBm (GPON) l Transmission distance: 20KM
WIFI interface	l IEEE802.11b/g/n (TX power:17dBm/16dBm /15dBm), Up to 300Mbps l 2T2R, 5dBi external antenna l Support 13 Channels
LAN interface	1GE+1FE,Auto-negotiation, RJ45 ports

○ Function Data
XPON mode	Dual Mode, Can access EPON/GPON mainstream OLTs
Uplink mdoe	Bridging and Routing Mode
Firewall	Filtering Based on ACL/MAC/URL
Layer2	802.1D&802.1ad bridge,802.1p Cos,802.1Q VLAN
Layer3	IPv4/IPv6 , DHCP Client/Server , PPPoE ,NAT , DMZ ,DDNS
Multicast	IGMP v1/v2/v3 , IGMP snooping
Security	Flow & Storm control, Loop Detection
O&M	l WEB/TELNET/OAM/OMCI l Support private OAM/OMCI protocol l Unified network management of VSOL OLT
WiFi	l Authentication:WEP/WAP-PSK(TKIP)/WAP2-PSK(AES) l Support multiple SSID
