V.SOL

1GE+3FE+2POTS+WiFi+USB ONU

Name: 1GE+3FE+2POTS+WiFi+USB ONU
Brand: V.SOL
Availability: InStock
Rating: 5.0 (10 reviews)

Model: HG326N , Spec: 1GE+3FE+2POTS+WiFi+USB

Contact Now

DataSheet PDF

Description
Reviews

Specifications

Product Description

The HG326N is a versatile and feature-rich Optical Network Unit (ONU) device that offers a comprehensive and high-speed internet connectivity solution. With its advanced features and robust design, it is ideal for homes, small businesses, and enterprises.

Key Features:

1 Gigabit Ethernet (GE) port for high-speed internet access
3 Fast Ethernet (FE) ports for connecting multiple devices
2 POTS (Plain Old Telephone Service) ports for voice connectivity
WiFi support for wireless connectivity
USB port for connecting external devices or charging
Compact and wall-mountable design for easy installation

Technical Specifications:

Model: HG326N
Interface: 1 GE + 3 FE + 2 POTS + WiFi + USB
WiFi Standards: 802.11n
Power Supply: DC 12V, 1A
Dimensions: 180mm x 120mm x 30mm
Operating Temperature: 0°C to 40°C
Humidity: 5% to 90% non-condensing

Benefits:

High-speed internet access with Gigabit Ethernet port
Multiple device connectivity with 3 Fast Ethernet ports
Voice connectivity with 2 POTS ports
Wireless connectivity with WiFi
External device connectivity and charging with USB port
Compact and easy-to-install design

Technical item	1GE+3FE+2POTS+WiFi+USB
PON interface	1 G/EPON port(EPON PX20+ and GPON Class B+) Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector Receiving saturation:≥-8dBm Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM
LAN interface	1 x 10/100/1000Mbps and 3 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless	Compliant with IEEE802.11b/g/n Operating frequency: 2.400-2.4835GHz support MIMO, rate up to 300Mbps 2T2R,2 external antenna 5dBi Support: multiple SSID Channel:13 Modulation type: DSSS、CCK and OFDM Encoding scheme: BPSK、QPSK、16QAM and 64QAM
POTS interface	2 FXS, RJ11 connector Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909
USB interface	USB 2.0
LED	13, For Status of PWR、PON 、LOS、WAN、WiFi、FXS1~2、ETH1~4、WPS、USB.
Operating condition	Temperature: 0℃～+50℃ Humidity: 5%～90%（non-condensing）
Storing condition	Temperature : -30℃～+75℃ Humidity :5%～90%（non-condensing）
Power supply	DC 12V,1/1.5A
Power consumption	≤10W
Dimension	205mm×140mm×37mm（L×W×H）
Net weight	0.34Kg
